Good vibrations

MIL-STD-810H vibration tested with impressive results in Category 9 – Helicopter Vibration 10-500 Hz

WaSP is our small but mighty solution for SWaP-C applications such as UAVs, drones and communication systems. A key feature of WaSP is MIL standard vibration testing, excelling in Category 9 – Helicopter Vibration 10-500 Hz.

WaSP

Based on our TERRAPIN SCE2 series the WaSP range takes the compact, rugged, lightweight designs and optimises them for high-volume, low-cost applications.

Features

Lightweight aluminium shell
Lightweight 1/4 turn polymer locking ring
No jam nut
Simplified geometry
Passivation anticorrosion layer
Vibration tested to MIL-STD-810H
Sealed IP67

Applications

Military drones
Commercial drones
Industrial applications
Ruggedised communication systems
Satellite broadband
Sensor applications

Technicals

Size 6, 7 way planform with the intention to add further versions
3A current rating per contact
10mΩ shell to shell conductivity
10mΩ max. contact resistance
400V working voltage
Operating temperature -55°C to 85°C
IP67 sealed
Salt spray 96 hours
RoHS compliant and suitable for RoHS compliant soldering
