Designed for demanding environments across military and commercial drones, industrial systems, ruggedised communications, satellite broadband and sensor applications. Small. Tough. Ready.

WaSP

Based on our TERRAPIN SCE2 series the WaSP range takes the compact, rugged, lightweight designs and optimises them for high-volume, low-cost applications.

Features

Lightweight aluminium shell
Lightweight 1/4 turn polymer locking ring
No jam nut
Simplified geometry
Passivation anticorrosion layer
Vibration tested to MIL-STD-810H
Sealed IP67

Applications

Military drones
Commercial drones
Industrial applications
Ruggedised communication systems
Satellite broadband
Sensor applications

Technicals

Size 6, 7 way planform with the intention to add further versions
3A current rating per contact
10mΩ shell to shell conductivity
10mΩ max. contact resistance
400V working voltage
Operating temperature -55°C to 85°C
IP67 sealed
Salt spray 96 hours
RoHS compliant and suitable for RoHS compliant soldering

Datasheets, Catalogues and Documentation

You can download all the information you need below.

Catalogue AMPHENOL_WaSP_Catalogue_Jan_2026

Get a quote Email us

Visit the Resource Hub

If you need technical specifications, 3D models or further information, visit our Resource Hub.

3D Models & Drawings
